Super Duplex UNS S32760 Seamless Pipe Supplier in India
Though the basic chemical makeup for both materials i.e. UNS S32760 and UNS S32750 is the same, the former contains additions of two elements i.e. - tungsten and copper. The use of ASTM A790 UNS S32760 Seamless Pipe is specifically applied to businesses that deal with the presence of high levels of chloride ions. The presence of Chloride ions in application often incurs a loss, particularly if regular steels are used, as they are easily decayed. Yet, the mere use of astm a790 grade s32760 material is what keeps the business from having a major setback in terms of cost efficiency.
ASTM A790 UNS S32760 Pipe
UNS S32760 Super Duplex Tube
Cost-efficiency, today is a trait desired by many industries, as they look for long term sustenance. In addition to having good corrosion resistance properties, the astm a790 uns s32760 seamless pipe offers superior mechanical properties as well, thereby increasing its value as an asset in several processes based piping systems. Usually, process piping systems regularly employ various halide containing compounds. If these systems were to use a regular pipe instead of an astm a790 uns s32760 pipe, they would be susceptible to pitting, localized corrosion, and erosion corrosion as well. However, the high mechanical strength in combination with its unique corrosion resistance properties and good resistance to fatigue makes the asme sa a790 s32760 material a highly appreciated one in industries like oil & gas, hydropower, pressure vessels, structural components, and chemical tankers, as well as the pulp & paper industry. In order to achieve such properties, the sa 790 uns s32760 material is often put through a solution annealing process. one of the biggest UNS S32760 Super Duplex Tube supplier in India who can provide material with mirror polish pipe
View ASTM A790 UNS S32760 Seamless & Welded Tube price per meter ex Mumbai
Table of Content
ASTM A790 Uns S32760 Seamless Pipe Specification Format
PED Approved Manufacturer and Supplier of ASTM A790 UNS S32760 Welded tubing in India
| Pipe Specifications | ASTM A790 UNS S32760 |
|---|---|
| Pipe Standard | AISI, DIN, EN, GB, JIS, ASTM, ASME Pipe |
| Seamless Pipe Outer Diameter | 6.00 MM OD up to 250 MM OD, Sizes up to 12 Inch NB |
| Welded Pipe size | 5.0 mm - 1219.2 mm |
| EFW Pipe size | 5.0 - 1219.2 MM |
| Pipe Thickness | 0.3 - 50 MM |
| Seamless Tube Size | 3.35 MM OD To 101.6 MM OD, 15 NB to 150 NB Inch |
| Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Tube Swg and Bwg | 10, 12, 14, 16, 18, 20 Swg. |
| tubing wall thickness | 0.020" –0.220" (special wall thicknesses for Pipe available) |
| Pipe Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS ASTM A790 UNS S32760 Pipe Supplier |
| Pipe and Tube Finish | Polished, Annealed and Pickle, MF, Bright and Annealed, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish etc |
| Pipe and Tube Form | Rectangular, Round, Square, Coiled, Hollow, Hydraulic, Straight Pipes, U Shape, Pan Cake Coils etc. |
| Pipe and Tube Length | Single Random, Double Random, Standard and Cut length |
| Pipe and Tube End | Plain End, Beveled End, Treaded Pipe |
| Pipe and Tube Type | Seamless, ERW, EFW, Welded, Fabricated, CDW, DOM and CEW Pipe |
| Pipe Marking | All Pipes are marked as follows: Supplier and Manufacturer’s Name, Grade, Standard, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Tube Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Pipe Value Added Service provided by suppliers | Draw and Expansion as per required Size and Length, Polish, Electro and Commercial, Annealed & Pickled Bending, Machining Etc. |
| Specialized in | Large Diameter Pipe Capillary Tube and Other Odd Size Heat Exchanger and Condenser Tubes |
| Pipe Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Heat Treatment Charts, Tubes HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP), Manufacturer Test Certificate , Laboratory Test Certificate from Govt. Approved Lab. |
| We can also cut, thread, and groove Pipe and Tubes to meet your specifications. | |
We can provide ASTM A790 UNS S32760 Seamless Pipe thickness from 1.2mm to 2mm. The pipe length standard size 3 meter, 6 meter and 10 meter. But we are one of the supplier who provide exact length pipe in all grade which saves your cost and avoid wastage. Perfect Impex is ASTM A790 UNS S32760 Seamless Pipe supplier who stock pipes in all surface finish
Common Types Of SA 790 UNS S32760 Welded Pipe
UNS S32760 Pipe
ASTM A790 UNS S32760 Seamless Pipe
ASTM A790 UNS S32760 Pipe
UNS S32760 Coil Tubes
UNS S32760 Capillary Tubes
ASTM A790 UNS S32760 Tube
UNS S32760 Welded Pipe
Super Duplex SA 790 S32760 Pipe
ASME SA790 UNS S32760 Pipe
Duplex S32760 boiler tube
Duplex Stainless Steel S32760 Instrumentation Tubes
DIN 1.4501 heater Tube
Duplex Stainless Steel UNS S32760 Clad Pipe
SCH20 Duplex 2507 UNS S32760 pipe
1.4501 S32760 Round Pipe
Hot Rolled Duplex 2507 UNS S32760 Pipe
Size Chart Of ASTM A790 UNS S32760 Pipe
Check sizes and dimensions of ASME SA790 UNS S32760 Heat Exchanger Tubes & Boiler Tubing
| Pipe OD mm |
Pipe WT mm |
in. | Sch | Kg/m |
|---|---|---|---|---|
| 13.72 | 1.65 | 1/4 | 10S | 0.50 |
| 13.72 | 2.24 | 1/4 | 40S | 0.64 |
| 13.72 | 3.02 | 1/4 | 80S | 0.81 |
| 17.15 | 1.65 | 3/8 | 10S | 0.64 |
| 17.15 | 2.31 | 3/8 | 40S | 0.86 |
| 17.15 | 3.20 | 3/8 | 80S | 1.12 |
| 21.34 | 2.11 | 1/2 | 10S | 1.02 |
| 21.34 | 2.77 | 1/2 | 40S | 1.29 |
| 21.34 | 3.73 | 1/2 | 80S | 1.65 |
| 26.67 | 2.11 | 3/4 | 10S | 1.30 |
| 26.67 | 2.87 | 3/4 | 40S | 1.71 |
| 26.67 | 3.91 | 3/4 | 80S | 2.23 |
| 33.40 | 2.77 | 1 | 10S | 2.13 |
| 33.40 | 3.38 | 1 | 40S | 2.54 |
| 33.40 | 4.55 | 1 | 80S | 3.29 |
| 33.40 | 6.352) | 1 | 160 | 4.30 |
| 42.16 | 2.77 | 1¼ | 10S | 2.73 |
| 42.16 | 3.56 | 1¼ | 40S | 3.44 |
| 42.16 | 4.85 | 1¼ | 80S | 4.53 |
| 42.16 | 6.352) | 1¼ | 160 | 5.69 |
| 48.26 | 2.77 | 1½ | 10S | 3.16 |
| 48.26 | 3.68 | 1½ | 40S | 4.11 |
| 48.26 | 5.08 | 1½ | 80S | 5.49 |
| 60.33 | 2.77 | 2 | 10S | 3.99 |
| 60.33 | 3.91 | 2 | 40S | 5.52 |
| 60.33 | 5.54 | 2 | 80S | 7.60 |
| 60.33 | 8.742) | 2 | 160 | 11.29 |
| 73.03 | 3.05 | 2½ | 10S | 5.35 |
| 73.03 | 5.16 | 2½ | 40S | 8.77 |
| 73.03 | 7.01 | 2½ | 80S | 11.59 |
| 88.90 | 3.05 | 3 | 10S | 6.56 |
| 88.90 | 5.49 | 3 | 40S | 11.47 |
| 88.90 | 7.62 | 3 | 80S | 15.51 |
| 88.90 | 11.132) | 3 | 160 | 21.67 |
| 101.60 | 3.05 | 3½ | 10S | 7.53 |
| 101.60 | 5.74 | 3½ | 40S | 13.78 |
| 101.60 | 8.08 | 3½ | 80S | 18.92 |
| 114.30 | 3.05 | 4 | 10S | 8.50 |
| 114.30 | 6.02 | 4 | 40S | 16.32 |
| 114.30 | 8.56 | 4 | 80S | 22.67 |
| 114.30 | 13.492) | 4 | 160 | 34.05 |
| 141.30 | 6.55 | 5 | 40S | 22.10 |
| 141.30 | 9.53 | 5 | 80S | 31.44 |
| 141.30 | 15.882) | 5 | 160 | 49.87 |
| 168.28 | 3.4 | 6 | 10S | 14.04 |
| 168.28 | 7.11 | 6 | 40S | 28.69 |
| 168.28 | 10.97 | 6 | 80S | 43.21 |
| 168.28 | 14.27 | 6 | 120 | 54.75 |
| 168.28 | 18.262) | 6 | 160 | 68.59 |
| 219.08 | 8.18 | 8 | 40S | 43.20 |
| 219.08 | 12.7 | 8 | 80S | 65.63 |
| 219.08 | 18.23 | 8 | 120 | 91.30 |
| 219.08 | 23.012) | 8 | 160 | 112.97 |
UNS S32760 Coil Tubes Schedule chart
| 1/8" IPS(.405" O.D.) | 3 1/2" IPS( 4.000" O.D.) |
|---|---|
| Duplex Pipes, SCH 40, 80 | Duplex Pipes, SCH 10, 40, 80, 160, XXH |
| 1/4" IPS(.540" O.D.) | 4" IPS(4.500" O.D.) |
| Duplex Pipes, SCH 10, 40, 80 | Duplex Pipes, SCH 10, 40, 80, 160, XXH |
| 3/8" IPS(.675" O.D.) | 5" IPS( 5.563" O.D.) |
| Duplex Pipes, SCH 10, 40, 80 | Duplex Pipes, SCH 10, 40, 80, 160, XXH |
| 1/2" IPS(.840" O.D.) | 6" IPS(6.625" O.D.) |
| Duplex Pipes, SCH 5, 10, 40, 80, 160, XXH | Duplex Pipes, SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4" IPS(1.050" O.D.) | 8 ” IPS(8.625" O.D.) |
| Duplex Pipes, SCH 10, 40, 80, 160, XXH | Duplex Pipes, SCH 5, 10, 40, 80, 120, 160, XXH |
| 1" IPS:(1.315′ O.D.) | 10" IPS(10.750" O.D.) |
| Duplex Pipes, SCH 5, 10, 40, 80, 160, XXH | Duplex Pipes, SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4" IPS(1.660" O.D.) | 12" IPS(12.750" O.D.) |
| Duplex Pipes, SCH 10, 40, 80, 160, XXH | Duplex Pipes, SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2" IPS(1.900" O.D.) | 14" IPS(14.000" O.D.) |
| Duplex Pipes, SCH 10, 40, 80, 160, XXH | Duplex Pipes, SCH10 (.188), SCH40 (.375) |
| 2" IPS(2.375" O.D.) | 16" IPS(16.000" O.D.) |
| Duplex Pipes, SCH 10, 40, 80, 160, XXH | Duplex Pipes, SCH10(.188), SCH40(.375) |
| 2 1/2" IPS(2.875" O.D.) | 18" IPS (18.000" O.D.) |
| Duplex Pipes, SCH 10, 40, 80, 160, XXH | Duplex Pipes, SCH-40 (.375) |
| 3" IPS( 3.500" O.D.) | |
| Duplex Pipes, SCH 5, 10, 40, 80, 160, XXH |
ASME SA A790 S32760 CDS Pipe Chemical Equation
| % | Cr | Ni | Mo | Cu | W | C | N | Mn | Si | P | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Min | 24 | 6 | 3 | 0.5 | - | 0.2 | - | - | - | - | - |
| Max | 26 | 8 | 4 | 1 | 0.03 | 0.3 | 1 | 1 | 0.030 | 0.010 | Balance |
ASTM A790 UNS S32760 Pipe Mechanical Behaviour
| 20 °C | 100 °C | 150 °C | 200 °C | 250 °C | |
|---|---|---|---|---|---|
| Ultimate Tensile Strength, MPa | 751.5 | 703.3 | 682.6 | 669 | 648.1 |
| 0.2% Yield Strength, MPa | 551.6 | 469 | 448.2 | 427.5 | 400 |
UNS S32760 Seamless Pipe Price List
Best price of S32760 Super Duplex Stainless Steel Tubing, Ready stock for urgent requirements
| ASTM A790 UNS S32760 Seamless Pipe Price | Price in INR | Price in USD |
|---|---|---|
| Super Duplex UNS S32760 Seamless Pipe 4 X schedule 160 x 2M (Heat No.48093) | INR 120,414 | USD 1642.86 |
| ASTM A790 seamless Pipes 6 schedule 40 X 2 M (3 Pcs) | INR 20,557 | USD 280.47 |
| Super duplex SAF UNS s32760 seamless pipes 2 X schedule 10 X 14 | INR 3,776 | USD 51.52 |
| Super Duplex Seamless Pipes Astm A790 UNS 32750 Seamless 3/4 X schedule 10S | INR 17,281 | USD 235.77 |
Corrosion Resistance Comparison of Duplex Stainless Steel S32760 pipe
| Alloy | % Mo | CCCT, °C (°F) | CPT, °C (°F) | PREN |
|---|---|---|---|---|
| 316L | 2.1 | < -2.22 (28) | 20 (68) | 24 |
| 2205 | 3.1 | 20 (68) | 49 (120) | 35 |
| 904L | 4.4 | 24 (75) | 54.4 (130) | 36 |
| UNS S32760 | 3.5 | 42.2 (108) | 82 (180 ) | 41 |
| AL-6XN | 6.2 | 43.3 (110) | 82 (180 ) | 44 |
| 625 | 9 | 45 (113) | - | 51 |
| C22 | 13 | - | - | 64 |
| C-276 | 15.5 | 54.4 (130) | > 103 (217) | 67 |
ASTM A790 UNS S32760 Pipe Application
- Suitable to use in Desalination plants
- Valves and pumps
- Seawater systems
- Used for Heat exchangers
- Subsea pipework systems
- Flue gas desulphurisation (FGD) plants
- Centrifuges and agitators
- Storage tanks and pressure vessels
